In 2004, I bought a new laptop. It was a Gateway 200X (Do you remember the cow boxes? I remember the cow boxes). I was a fairly serious Linux user at the time, so I installed Gentoo Linux on it. Just about everything worked right away, which at the time was both surprising and a little disappointing. It hadn’t been too long since things like USB support meant you were recompiling your kernel, so rebooting from the installer into a fully functional environment left me feeling a little empty. It was a different time.

I think this was my first laptop. So for the first couple of weeks I shut it down from the power menu the way you (or at least I) shut down a desktop. It never crossed my mind to hit the power button to shut it down. One evening, I decided to try that. I hit the power button … and nothing happened.

My heart leapt. Here was a thing that didn’t work! It also was right around Christmas, so I was about to have a bunch of time off. Ideal conditions to figure out how to shut down my computer from the power button. What better way to spend a holiday?

What followed was an odyssey that in many ways shaped the rest of my life. I’ll skip a lot of the details about how I got it working. Most of them are irrelevant today, and the specific steps are beside the point. What’s important is the fact that I had to go searching.

I learned that there was a specification for power management (ACPI), and that it was published and I could read it. I learned that most laptops at the time didn’t follow it terribly strictly. I learned that there was a programming language for it, and that I could fix my own broken power management by using it. I learned that I had to patch the linux kernel to fix some things and I even learned how to write a kernel patch that would appall anybody who’s written a real kernel patch.

After about a week of research, trial and error, qualified successes, and setbacks, the moment came when I hit the power button and watched my laptop gracefully shut down. I spent the next 15 minutes just turning it on and turning it back off again. I showed my wife, who graciously feigned excitement. It was immensely gratifying.

I’d seen enough questions about ACPI on the Gentoo Linux forums that I wrote a guide. This was also a learning experience! When I get into writing something, I have a lot of fun. I like to tell little anecdotes, make bad jokes, go off on the occasional tangent. It turns out that when someone is reading in order to fix something that’s broken, they don’t want any of that! I edited my guide constantly, revising it based on feedback. I learned a lot about what makes good technical writing and what doesn’t.

I also got to help a lot of people directly. Every time I was able to help someone fix their computer’s ACPI implementation, I felt genuine joy. It was even more gratifying than getting it to work for myself.

Friction hampers productivity, but it stokes curiosity. Productivity gets things done, but curiosity lets us ask whether the thing we’re doing should get done. I once had a physics teacher who said that without friction, we’d slide off the world. As I see how effortlessly people bring harm to one another with the frictionless technologies we’ve built, I feel that we’re doing exactly that. I long for the friction that can stop the slide and let us remember what it is to be rooted in community.

Had that power button just worked all those years ago, I’d have missed out on all of this learning. But because it didn’t, I gained a deeper understanding not just of how my laptop worked, but of how I work. Each question I asked led me to another question. As I started to understand my specific problem, I started to ask different questions. What other things are broken in my ACPI implementation? Can I fix those? Are other people having similar problems? Can I help them?

The answers to those questions have shaped much of the last 20 years of my life. They’ve changed my career. They’ve introduced me to new hobbies. They’ve brought me to communities both physical and virtual. I would not be the person I am today if I hadn’t asked them.

And it all happened because nothing happened.

This is a guide that I wrote for the gentoo forums in 2004. I’ve been thinking about submitting a piece for this month’s IndieWeb Carnival and I think my experience with ACPI in the early 2000s is a good topic for the theme: On the Importance of Friction.

It also struck me that this is a good thing to preserve on my own site. It remains one of my proudest writing accomplishments, and although it’s long since defunct, I’d feel a sense of loss if the gentoo forums were to disappear and this were to be lost.

So, I’m republishing it here for posterity. If you should stumble across it because you’re actually looking for information about ACPI on Linux, I beg you, _stop reading now. There is nothing here that is of any technological value in 2025. Some of it may hold entertainment value, depending on what you find entertaining.

HOWTO: Fix Common ACPI Problems (DSDT, ECDT, etc.)

NOTE (2009-11-09): This guide is coming up on 6 years old, so it’s probably pretty outdated, especially where kernel options and such are concerned. Some of the links are also stale.

For the past few weeks, I’ve been wrestling with ACPI on my laptop (a Gateway 200X). The main problems are that it has a buggy DSDT and a missing ECDT. A bit of googling revealed that neither is an uncommon problem. Unfortunately, some other OSes are more forgiving of deviations from the ACPI spec than they should be, and that causes problems for the rest of us. The only real solutions are to provide a fixed DSDT and ECDT to the kernel.

Now when I heard this, at first I was afraid. I was petrified. But as it turned out, it wasn’t so hard to fix the problem. The trickiest part was diagnosing it; from there (in my case at least) the fix was very straightforward. Here’s how to go about doing it if you are also having trouble with ACPI on your machine. Much of this is taken from this post, but I’ve weeded out some other stuff that was more specific to my machine.

NOTE

This involves some kernel patching, and possibly overwriting your existing initrd. PLEASE make backups of important things. In particular, I found that backups of my kernel configs, working kernels and bootsplash initrd were extremely helpful.

Table of Contents

Revisions
Definitions
Description of the Problem
Disclaimer
Tested Kernels (DSDT override)
What you'll need to fix your DSDT
Diagnosing a Buggy DSDT
Fixing the DSDT
Incorporating the fixed DSDT into the kernel
    Static DSDT override
    initrd DSDT override
    initrd override with bootsplash
My DSDT is fixed, but I still have ACPI errors. Now what?
    Windows-only DSDT functionality
    Missing ECDT
    My power and/or sleep buttons don't work
    My BIOS is blacklisted
    I have an Asus laptop
    It's still not working!
Useful ACPI resources
Acknowledgements

1. Revisions

   01/08/2004

   • Added three new sections:
     1. Revisions
     2. Definitions
     3. Description of the Problem

   01/09/2004

   • Tested with some 2.6 kernels
   • Added initrd patch section, corrected misinformation about bootsplash and initrd DSDT (it does work)
   • Reformatted to conform better to the guidelines
   • Added links to HOWTOs with fixes for common DSDT errors
   • Added fixes for warnings to the main doc[/list]

   01/10/2004

   • Added missing ACPI resource links
   • Corrected numerous typos

   01/11/2004 *Added Disclaimer section

   01/12/2004

   • Added explanation of “Return(Package(0x02){0x00, 0x00})” fix for _WAK method warning.

   01/13/2004

   • Modified Intel iasl links to point to the main download page. Thanks, Moled.

   01/14/2004

   • Clarified Description of the Problem, included Microsoft compiler information. Thanks, Kesereti.
   • Added link to the acpi.sourceforge.net DSDT Repository to section 8.

   01/25/2004

   • Added a couple paragraphs about acpi_os_name boot parameter to section 8.
   • Added new section for ECDT, acpi_os_name and ff button problems
   • Added a couple more links to patches
   • Removed To Do section, since it’s all done.
   • Renamed, because this has evolved into more of a general ACPI HOWTO

   01/26/2004

   • Clarified section 10a (Windows-only DSDT functionality)

   02/02/2004

   • Reformatted revisions as code block so they don’t take up so much space.
   • Added blacklisted BIOS section.
   • Added acpi4asus section.
   • Added brief information about some other acpi boot parameters to Section 10f.

2. Definitions

ACPI Machine Language (AML)

From the ACPI Spec, page 13:

Pseudocode for a virtual machine supported by an ACPI-compatible OS and in which ACPI control methods and objects are written.

This is what the DSDT is compiled to. An ACPI-compatible OS must be able to understand AML. You don’t have to be able to.

ACPI Source Language (ASL)

Again from the Spec, Page 13

The programming language equivalent for AML. ASL is compiled into AML images.

This is the language that the DSDT is written in. If you need to fix your DSDT, you’ll have to write at least a little bit of ASL.

Differentiated System Description Table (DSDT)

From the ACPI Spec, page 14:

An OEM must supply a DSDT to an ACPI-compatible OS. The DSDT contains the Differentiated Definition Block, which supplies the implementation and configuration information about the base system. The OS always inserts the DSDT information into the ACPI Namespace at system boot time and never removes it.

Well, of course :) Basically, what this boils down to is that the DSDT describes the configuration of your system. It has definitions of all of the devices that ACPI supports, and describes their capabilities. So, for example, it describes the battery, AC Adapter, Embedded Controller, Fans and Thermal Zones. It presents this information in a hierarchical manner, so that ACPI (and therefore the OS) can be aware of dependency relationships among the system hardware. The DSDT is loaded at boot time. It basically tells the ACPI drivers what to watch out for.

3. Description of the Problem

The ACPI Specification defines the requirements for the DSDT (and everything else, for that matter) pretty explicitly. Intel’s ASL compiler, iasl, used to compile the DSDT to AML from ASL, will throw errors and warnings if the underlying ASL is buggy. Unfortunately, Microsoft’s ASL compiler allows many of these errors and warnings to sneak by. As a result, many OEMs write buggy DSDTs, and it turns out that Windows is very forgiving of bugs in the DSDT that get by Microsoft’s compiler (not surprisingly).

What this means is that a DSDT that does not conform to the ACPI specification will work under Windows, even though it shouldn’t. However, when you try to use it in Linux, where the ACPI developers expect that the DSDT is written to comply with the standard (and the Intel ASL compiler), the buggy sections of the DSDT are unsupported. If you have a buggy DSDT, ACPI may not be aware that certain devices exist. Or, if it is aware, it may not support all of their capabilites. If you have either of these symptoms (missing or incompletely supported functionality in /proc/acpi), then the cause may be a buggy DSDT.

You can tell whether your DSDT was compiled with the Microsoft compiler by the presence of “MSFT” in the DSDT line in dmesg, as below:

ACPI: RSDP (v000 GBT ) @ 0x000f6d20
ACPI: RSDT (v001 GBT AWRDACPI 0x42302e31 AWRD 0x01010101) @ 0x3fff3000
ACPI: FADT (v001 GBT AWRDACPI 0x42302e31 AWRD 0x01010101) @ 0x3fff3040
ACPI: MADT (v001 GBT AWRDACPI 0x42302e31 AWRD 0x01010101) @ 0x3fff7080
ACPI: DSDT (v001 GBT AWRDACPI 0x00001000 MSFT 0x0100000c) @ 0x00000000

Ideally, we could each convince our favorite purveyor of laptops to fix their DSDTs. That’s a good idea, but while we’re waiting for hell to freeze over, we can implement a workaround to fix our DSDTs ourselves, and provide the fixed DSDT to the linux kernel, making it content, perhaps even happy.*

In addition to the DSDT, laptops that conform to the ACPI 2.0 specification may provide an ECDT. This is a small table that provides minimal information about the Embedded Controller to the ACPI drivers before this section is parsed from the DSDT. This is necessary to prevent some chicken and egg type problems with initializing devices (such as the battery and ac adapter in some systems) that rely on the Embedded Controller. Sadly, again, some laptops that should provide an ECDT do not. So, to get around this, we’ll have to patch the kernel to read the necessary information from the DSDT.

*Kernel happiness not guaranteed. The author does not take responsibility for surly kernels.

4. Disclaimer

The processes outlined here should help you to solve many common problems with ACPI under linux. However, they will not necessarily solve all of your ACPI problems. Unfortunately, there are many causes of ACPI trouble. If after trying these fixes, your ACPI problems persist, then you may have found a bug in the ACPI driver code, which is still under active development. You may also have found a system-related issue of which I am not aware. In either case, your best options are to send an email to the acpi-devel mailing list or to open up a bug at bugzilla. Sometimes, it’s best to let the pros handle things.

But enough about what this can’t fix. Let’s dig into the things that it can. First things first - let’s make sure we have a good DSDT.

5. Tested Kernels (DSDT override)

The DSDT override procedures outlined in the following sections have been tested successfully with the following kernels:

2.4.23 vanilla with ACPI patches from acpi.sourceforge.net (static DSDT)
2.4.24 vanilla (static DSDT, initrd DSDT)
2.6.0 vanilla (initrd DSDT)
2.6.0-gentoo (initrd DSDT + bootsplash)
2.6.1-rc1 vanilla (static DSDT)
2.6.1 vanilla (initrd DSDT)

6. What you’ll need to fix your DSDT

Before you get started fixing your DSDT, you will need the following:

ACPI support compiled into your kernel (static or modules), so you have a /proc/acpi directory.
The latest ACPI patches from acpi.sourceforge.net (if using vanilla sources).
The Intel asl compiler, available here.
and EITHER
The static DSDT override patch (tested with kernels 2.4.23 and above), available here
OR
The initrd DSDT override patch appropriate for your kernel, avaliable here

7. Diagnosing a Buggy DSDT

Obviously, fixing your DSDT won’t be of any help if it isn’t broken. So, the first thing we have to do is find out if it is buggy or not. The easiest way to do this is to recompile the DSDT and see if we get any errors from the compiler. In order to do that, we’ll need the iasl compiler and the DSDT to compile. First, let’s get the compiler ready:

Get the iasl compiler here.
su to root (not really necessary yet, but you'll need to be root eventually, so why not?)
Extract the iasl compiler to a directory somewhere.

Code:
tar -xvzf iasl-linux-20030228.tar.gz

Enter the newly created directory. You should see a file called iasl. That's the compiler. For simplicity, I'll assume that the rest of the diagnostic steps are done from this directory.

Code:
cd iasl-linux-20030228
ls
>> AslCompiler.pdf     iasl


Now we need to get the current DSDT, disassemble it and recompile it to see if we get any errors.

Extract your current DSDT to a file as follows:
Code:
cat /proc/acpi/dsdt > dsdt.dat


This will give you a file, dsdt.dat that contains your current compiled dsdt. Now we have to disassemble it so we can recompile it. To do that, we'll use iasl.

Disassemble the DSDT
Code:
./iasl -d dsdt.dat

This will create a file called dsdt.dsl, which contains the disassembled DSDT. Have a look at it if you like. You can view its contents with any text editor. Now we need to recompile it, again with iasl.

Recompile the DSDT.
Code:
./iasl -tc dsdt.dsl

This will create two files, dsdt.hex and DSDT.aml.

That’s it! If your DSDT is buggy, then you’ll see some errors and/or warnings when you recompile. For instance, on my laptop, I got the following messages when recompiling:

Code:

Intel ACPI Component Architecture
ASL Optimizing Compiler / AML Disassembler version 20030228 [Feb 28 2003]
Copyright (C) 2000 - 2003 Intel Corporation

Supports ACPI Specification Revision 2.0b

dsdt.dsl   163:     Method (\_WAK, 1, NotSerialized)
Warning  2026 -                ^ Reserved method must return a value (\_WAK)

dsdt.dsl  2626:                     Field (ECR, DWordAcc, Lock, Preserve)
Error    1048 -                              ^ Host Operation Region requires ByteAcc access

dsdt.dsl  2672:                     Method (\_GLK, 1, NotSerialized)
Warning  2024 -                                ^ Reserved method has too many arguments ( \_GLK requires 0)

ASL Input:  dsdt.dsl - 3759 lines, 123154 bytes, 1862 keywords
Compilation complete. 1 Errors, 2 Warnings, 0 Remarks, 390 Optimizations

One error, two warnings. In my case, the error was the source of my trouble. So, if we can fix that up, it should help. At this point, you’re done diagnosing the problem. If you got errors from recompiling, then you have a buggy DSDT. The next step is to fix it.

8. Fixing the DSDT

The first thing that you should do if you have a buggy DSDT is to head over to the DSDT repository at acpi.sourceforge.net. They have fixed DSDTs for a number of laptops, so your model may already have a fix available. If there is a fix there, then just download it, extract it, recompile the asl using iasl as above, and proceed to Section 9. If there isn’t already a fixed DSDT available, then you will have to try to fix your DSDT yourself. Read on for an example from my machine.

Unfortunately, this step will differ for every system. In my case, the fix was simple and self-evident, but I can’t guarantee that that will be the case with you. You can find solutions to common DSDT compilation errors here. At the end of the document, I’ll have a list of useful resources in case you get stuck. OK - on to the fixing!

In order to fix the DSDT, you’ll have to edit the dsdt.dsl file that we created in the diagnosis. Let’s use mine as an example. Unless you also have a Gateway 200X, your process will be different (and if you do have a 200X, then you can get the fixed DSDT here). However, this should at least give you an overview of the process.

As you may recall, when I compiled my DSDT, I got one error:

Code:

dsdt.dsl  2626:                     Field (ECR, DWordAcc, Lock, Preserve)
Error    1048 -                              ^ Host Operation Region requires ByteAcc access

This tells me the following:

• The error is on line 2626
• The region in question requires ByteAcc Access

Since I see that this line has a DWordAcc value specified, I assume that that is what is causing the problem. So, I opened dsdt.dsl in a text editor and fixed that line:

Edit dsdt.dsl
Code:
vi dsdt.dsl

Change any lines that are raising errors. I changed line 2626 from this
Code:
Field (ECR, DWordAcc, Lock, Preserve)

to this
Code:
Field (ECR, ByteAcc, Lock, Preserve)


Save and close the file. Now that we've made the change, we have to recompile to see if we actually fixed the problem.

Recompile dsdt.dsl
Code:
./iasl -tc dsdt.dsl

Now, when I recompile, I get the following:
Code:
Intel ACPI Component Architecture
ASL Optimizing Compiler / AML Disassembler version 20030228 [Feb 28 2003]
Copyright (C) 2000 - 2003 Intel Corporation
Supports ACPI Specification Revision 2.0b

dsdt.dsl   163:     Method (_WAK, 1, NotSerialized)
Warning  2026 -                ^ Reserved method must return a value (_WAK)

dsdt.dsl  2672:                     Method (_GLK, 1, NotSerialized)
Warning  2024 -                                ^ Reserved method has too many arguments ( _GLK requires 0)

ASL Input:  dsdt.dsl - 3759 lines, 123153 bytes, 1862 keywords
AML Output: DSDT.aml - 14600 bytes 499 named objects 1363 executable opcodes

Compilation complete. 0 Errors, 2 Warnings, 0 Remarks, 390 Optimizations


Alright! The error is gone. The warnings are still there, though. Let's get rid of them now, too.

Repeat steps 1-3 for the warnings

The second warning seems to be the easier one:
Code:
dsdt.dsl  2672:                     Method (_GLK, 1, NotSerialized)
Warning  2024 -                                ^ Reserved method has too many arguments ( _GLK requires 0)


So, the _GLK method has too many arguments. Let's get rid of them. We can fix this by changing line 2672 from this:
Code:
Method (_GLK, 1, NotSerialized)

to this:
Code:
Method (_GLK)


Recompiling now only gives me the one warning:
Code:
dsdt.dsl   163:     Method (_WAK, 1, NotSerialized)
Warning  2026 -                ^ Reserved method must return a value (_WAK)


From this HOWTO, I see that the solution is to add the following line to the end of the _WAK method:
Code:
Return(Package(0x02){0x00, 0x00})


What does this line mean? A little digging into the ACPI spec (Section 7.3.5) yields some information about the _WAK method.

Code:
Arguments:
0   The value of the sleeping state (1 for S1, 2 for S2, and so on).
Result Code (2 DWORD package):
Status   Bit field of defined conditions that occurred during sleep.
   0x00000000   Wake was signaled and was successful
   0x00000001   Wake was signaled but failed due to lack of power.
   0x00000002   Wake was signaled but failed due to thermal condition.
   Other   Reserved
PSS   If non-zero, the effective S-state the power supply really entered.

This value is used to detect when the targeted S-state was not entered because of too much current being drawn from the power supply. For example, this might occur when some active device’s current consumption pushes the system’s power requirements over the low power supply mark, thus preventing the lower power mode from being entered as desired.


OK, so the _WAK method accepts one argument, which is the number of the sleep state that was requested. It returns its result as a package of 2 DWORDs. The first value is a code that tells whether the wake was successful (0 on success, nonzero on failure) and, if not, why. The second value is also zero on success and on failure returns the value of the sleep state that was actually entered. So basically, it's a success/failure code.

In Chapter 16, we can find out how to define a Package.
Code:
PackageTerm   := Package(
                          NumElements  //Nothing |
                                       //ByteConstExpr |
                                       //TermArg=>Integer
                        ) {PackageList} => Package


The first argument of the package declaration specifies the number of elements in the package, and the second is the package itself. So, the declaration above simply defines a two element package, where each of the elements is zero. This is necessary because the spec requires that the _WAK method return two values.

So, what this really boils down to is a dummy return value that satisfies the spec (thus eliminating the warnings), but doesn't really do anything. It just always returns a "Success" condition.

OK, now that that is cleared up, I add that line, recompile, and.... (drum roll please)

Code:
Intel ACPI Component Architecture
ASL Optimizing Compiler / AML Disassembler version 20030228 [Feb 28 2003]
Copyright (C) 2000 - 2003 Intel Corporation
Supports ACPI Specification Revision 2.0b

ASL Input:  dsdt.dsl - 3760 lines, 123177 bytes, 1863 keywords
AML Output: DSDT.aml - 14606 bytes 499 named objects 1364 executable opcodes

Compilation complete. 0 Errors, 0 Warnings, 0 Remarks, 392 Optimizations

Excellent! No errors, no warnings. We now have a “fixed” DSDT (remember, the _WAK method isn’t really fixed, we’ve just shut up the warning on compile ;)). Many of the suggestions in the DSDT HOWTOs that I found are really just workarounds, not proper fixes. If you would like a more thorough analysis of your DSDT, you may want to ask the folks on the acpi-devel mailing list. If you succesfully used this process to fix your DSDT, please consider posting the fix to the DSDT repository, so that others can benefit from your work.

All that remains now is to convince our kernel to use the new DSDT.

As stated above, this will create two files, dsdt.hex and DSDT.aml. You will need to use one or the other of these files in the next step, depending on which method you use to override your DSDT. If you use the static DSDT override method, then you will need dsdt.hex. If you use the initrd method, then you will need DSDT.aml.

9. Incorporating the fixed DSDT into the kernel

There are two ways to incorporate your new DSDT into the kernel. The first way is to include it statically at compile time. The second is to pass it to the kenel at boot time as an initrd. The initrd approach is probably preferable, especially if you need to make a lot of changes to your DSDT, because it doesn’t require that you recompile your kernel for each new DSDT. The static method does. Each method requires a kernel patch. Let’s start with the static method first:

9a. Static DSDT override

To statically override your DSDT at kernel compile time, you will have to apply a patch to your kernel to have it read in the new DSDT, and then copy your fixed DSDT .hex file (dsdt.hex) to the kernel source tree for inclusion in the kernel.

So, first things first, let’s patch the kernel.

Obtain DSDT override patch from here
Save the file to your machine. Let's call it dsdt_override.diff.
Patch your kernel. I'm assuming that the kernel sources are located in /usr/src/linux-2.4.23, since that's the version I used. If yours are elsewhere, then modify the paths accordingly.
Code:
cd /usr/src/linux-2.4.23
patch -p1 < /path/to/dsdt_override.diff


If you don't get any errors, then the patch succeeded. The patch expects to find the fixed DSDT in the linux source tree, under includes/acpi. It expects it to be named dsdt_table.h. So, let's give it what it wants.

Copy dsdt.hex to the kernel source tree.
Code:
cp /path/to/dsdt.hex /usr/src/linux-2.4.23/include/acpi/dsdt_table.h

Recompile your kernel.

That ought to do it. After recompiling, move your new kernel image to /boot (maybe don’t overwrite your current kernel - just to be safe ;)), and reboot. If any of your acpi problems were caused by the buggy DSDT, then they should be fixed. /proc/acpi/dsdt should now contain your new fixed DSDT, so you can always cat that back out and recompile it to make sure that you are getting what you expect (i.e. no errors).

Remember, if you make more changes to your DSDT, then you’ll have to recopy it to /include/acpi/dsdt_table.h and recompile your kernel.

9b. initrd DSDT override

The initrd method requires about the same amount of setup as the static method for the initial DSDT, but any subsequent changes can be incorporated much more easily. Basically, you will have to patch your kernel, copy your fixed DSDT .aml file (DSDT.aml) to /boot, and direct the kernel to incorporate it as an initrd. If you are already using an initrd for something, then there is a bit more work involved. I’ll go over that after describing the basic case.

So, again, the first thing we have to do is patch the kernel.

Get the appropriate initrd patch for your kernel from here
Apply the patch to your kernel (in my case, I tested this on 2.6.0)
Code:
cd /usr/src/linux-2.6.0
patch -p1 < /path/to/acpi-dsdt-initrd-patch-v0.4-2.6.0.diff

Make sure that ramdisk and initrd support are compiled statically into the kernel
Code:
Device Drivers --->
    Block Devices --->
        <*> RAM disk support
        [*] Initial RAM disk (initrd) support

Make sure that the new "Read DSDT from initrd" option is selected under the ACPI menu
Code:
Power management options (ACPI, APM) --->
    ACPI (Advanced Configuration and Power Interface) Support --->
        [*] Read DSDT from initrd

Recompile the kernel

Great! Now the kernel is ready to accept a DSDT as an initrd. Next, we need to copy the fixed DSDT.aml file to /boot and edit our grub.conf to point to the DSDT.

Copy the fixed DSDT.aml to /boot:
Code:
mount /boot
cp /path/to/DSDT.aml /boot

Edit grub.conf to use the new DSDT as an initrd. For example, mine looks like this:
Code:
title=Gentoo Linux (2.6.0 - DSDT initrd)
root (hd0,5)
kernel (hd0,5)/boot/linux-2.6.0-dsdt-initrd root=/dev/hd8
initrd=/boot/DSDT.aml

The important line is the "initrd=" line. Please remember to use your actual paths for root and kernel - don't just copy this into your grub.conf verbatim.

When you reboot, the new kernel should pick up the DSDT from the /boot partition and load it up as directed by the initrd parameter. You should see a message in dmesg that says “Looking for DSDT in initrd …”

Now, if you make changes to your dsdt, all you have to do is copy the new DSDT.aml to /boot and reboot to incorporate those changes. No kernel recompile required.

9c. initrd override with bootsplash

If you are already using an initrd for something, like bootsplash, you can still use this method. You just have to create the initrd a bit differently. Instead of simply copying DSDT.aml to /boot and using it as the initrd, you have to cat a signature for the DSDT into your existing initrd, and then cat the DSDT into it as well. For example, my bootsplash initrd is currently called initrd-1024x768. So, here’s what I did to add the DSDT.

Make a copy of /boot/initrd-1024x768 for use with the DSDT
Code:
cp /boot/initrd-1024x768 /boot/initrd-1024x768-dsdt

Append the DSDT signature to the initrd
Code:
echo "INITRDDSDT123DSDT123" >> /boot/initrd-1024x768-dsdt

cat the fixed DSDT.aml into the initrd
Code:
cat /path/to/DSDT.aml >> /boot/initrd-1024x768-dsdt

Modify grub.conf to use the new initrd on boot:
Code:
title=Gentoo Linux (2.6.0 gentoo - bootsplash + DSDT initrd)
root (hd0,5)
kernel (hd0,5)/boot/linux-2.6.0-gentoo-dsdt root=/dev/hd8 video=vesa:ywrap,mtrr vga=0x317
initrd=/boot/initrd-1024x768-dsdt

Voila! When you boot up, you should now get your lovely bootsplash screen and your new dsdt, both incorporated from the initrd.

If you make changes to the DSDT, you just have to rebuild your initrd as above (which is a good reason to make a copy of your existing one, rather than appending to it directly).

10. My DSDT is fixed, but I still have ACPI errors. Now what?

10a. Windows-only DSDT functionality

You may find that you have no errors in your DSDT, but there are still errors in dmesg, or missing ACPI functionality. This may be because your DSDT is testing for the name of your OS. Many DSDTs do this, and enable certain functionality only if you are running a particular OS (usually, of course, Windows XP). To test for this, look for lines in your DSDT that check the value or length of the “_OS” variable. For example, you may find lines like this:

Code:

If (LEqual (SizeOf (\_OS), 0x14))

This is checking for an OS name with a length of 20 (0x14) characters. Some examples are “Microsoft Windows NT” or “Microsoft Windows XP”. You could try to rewrite your DSDT to skip these checks, or to provide the missing functionality for other OSes, but this is tedious and error-prone. Fortunately, there is a simpler way. There is a boot parameter that you can pass to the kernel to tell ACPI to pretend that you are running Windows to restore the missing functionality, rather than rewriting your DSDT. The parameter is called acpi_os_name. So, in grub.conf, you would just add this parameter to the kernel line, like this:

Code:

acpi_os_name="Microsoft Windows XP"

This should restore any functionality that is dependent on your OS identifying itself as Windows XP. Other common _OS length checks are:

0x11: “Microsoft Windows”

0x27: “Microsoft WindowsME: Millennium Edition”

NOTE

These tests are also sometimes used to disable certain functionality for certain Windows OSes. So, you may want to take a few minutes to try to work out what your DSDT is doing before fudging the OS name. You should probably take note of what works and what doesn’t before and after trying this, just in case you end up turning something off. :)

10b. Missing ECDT

If your problem isn’t that the DSDT is checking whether or not you are running Windows, then you may have a missing ECDT. The ECDT is used to provide some minimal information about the Embedded Controller to the ACPI drivers before the Embedded Controller region has actually been parsed from the DSDT. This is frequently necessary before initializing the battery and ac adapter, so if you have errors in dmesg from the battery, adapter or EmbeddedControl, the ECDT is the likely culprit. For instance, after fixing my DSDT, I had the following errors in dmesg:

Code:

evregion-0251 [22] ev\_address\_space\_dispa: No handler for Region [ECR\_] (df5ec688) [EmbeddedControl]
 exfldio-0284 [21] ex\_access\_region      : Region EmbeddedControl(3) has no handler
 dswexec-0435 [14] ds\_exec\_end\_op        : [LEqual]: Could not resolve operands, AE\_NOT\_EXIST
dswstate-0273 [16] ds\_result\_pop\_from\_bot: No result objects! State=df5fb428
 dsutils-0525 [16] ds\_create\_operand     : Missing or null operand, AE\_AML\_NO\_RETURN\_VALUE
 psparse-1120: \*\*\* Error: Method execution failed [\_SB\_.ADP1.\_STA] (Node df5f42c8), AE\_AML\_NO\_RETURN\_VALUE
evregion-0251 [22] ev\_address\_space\_dispa: No handler for Region [ECR\_] (df5ec688) [EmbeddedControl]
 exfldio-0284 [21] ex\_access\_region      : Region EmbeddedControl(3) has no handler
 dswexec-0435 [14] ds\_exec\_end\_op        : [LEqual]: Could not resolve operands, AE\_NOT\_EXIST
dswstate-0273 [16] ds\_result\_pop\_from\_bot: No result objects! State=df5fb428
 dsutils-0525 [16] ds\_create\_operand     : Missing or null operand, AE\_AML\_NO\_RETURN\_VALUE
 psparse-1120: \*\*\* Error: Method execution failed [\_SB\_.BAT1.\_STA] (Node df5f4848), AE\_AML\_NO\_RETURN\_VALUE

EmbeddedControl is obviously the embedded controller. ADP1 is the ac adapter and BAT1 is the battery. After booting, my /proc/acpi/ac_adapter and /proc/acpi/battery directories were empty. All of this was caused by the missing ECDT.

A couple of patches have been proposed to correct this behavior. So far, the most promising one is here. This defers the Embedded Controller’s initialization until it has actually been parsed from the DSDT. This patch restored my missing ECDT-related functionality (battery and adapter), and has been reported to do the same for a number of different systems. It may be applied to both the 2.4 and 2.6 kernel sources.

10c. My power and/or sleep buttons don’t work

The ACPI spec defines two types of power and sleep buttons. They are called fixed-feature (FF) buttons and control method (CM) buttons. The difference between the two is that FF buttons are defined at a lower level than the DSDT, in the FADT. CM buttons are defined in the DSDT. It is possible for your system to have both types of button. You can tell which you have by the presence of an “FF” or “CM” next to the button alert in dmesg. For example, my dmesg gives the following:

Code:

ACPI: Power Button (FF) [PWRF]
ACPI: Lid Switch [LID0]
ACPI: Sleep Button (CM) [SLPB]

So, acpi is detecting an FF power button and a CM sleep button. I actually also have a CM power button defined in my DSDT. However, in accordance with the ACPI spec, if the linux drivers detect an FF button, the CM button is ignored. Unfortunately, the FF power button does not generate an ACPI event in my case. However, the CM sleep button does generate events.

I opened a bug for this behavior. However, it is unlikely that the behavior will change, since it would contradict the spec to give CM buttons precedence over FF buttons. So, I posted a patch to provide a workaround for the problem on the 2.6 kernels.

The patch allows you to provide a new boot parameter, called ignore_ff_buttons. It accepts one of three values, PWRF (to ignore only the FF power button), SLPF (to ignore only the FF sleep button), or BOTH (to ignore both FF buttons).

In my case, I just want to ignore the FF power button, since I am already using the CM sleep button. So, I modified my grub.conf as below:

Code:

title=Gentoo Linux (2.6.1 - all ACPI patches)
root (hd0,5)
kernel (hd0,5)/boot/linux-2.6.1 root=/dev/hda8 ignore\_ff\_buttons=PWRF
initrd=/boot/DSDT.aml

Now, when I reboot, dmesg shows me the following buttons:

Code:

ACPI: Lid Switch [LID0]
ACPI: Sleep Button (CM) [SLPB]
ACPI: Power Button (CM) [PWRB]

And I get ACPI events from my power button.

NOTE

If you decide to use this patch, please be careful. I haven’t created a kernel patch before. This one doesn’t do much, so it should be pretty safe, but I highly recommend that you back up your kernel tree before applying it. Also, if you do decide to use it, I would be very interested to hear whether or not it works for you. Of course, I’m sure that I’ll hear if it doesn’t, but if it does, I would also like to know. :)

10d. My BIOS is blacklisted

Some BIOSes have been blacklisted by the ACPI developers because they have known problems. These problems are usually related to the DSDT, so you might be able to repair these problems using the above techniques. Unfortunately, if the ACPI code detects that you have a blacklisted BIOS, it will disable ACPI even if you have fixed your DSDT. If you have a blacklisted BIOS, you will see a message like this on boot:

Code:

ACPI: Vendor "PTLTD " System "  DSDT  " Revision 0x6040000 has a known ACPI BIOS problem.
ACPI: Reason: Multiple problems. This is a non-recoverable error
ACPI: BIOS listed in blacklist, disabling ACPI support

To get around this, you’ll have to comment out the line in the ACPI code that causes your BIOS to short circuit the ACPI startup process. The file that sets the blacklisted BIOSes is /usr/src/linux/drivers/acpi/blacklist.c. To prevent your blacklisted BIOS from causing trouble, open up the file and comment out the appropriate line in static struct acpi_blacklist_item acpi_blacklist[]. For example, in the above case, the line to comment is:

Code:

{"PTLTD ", "  DSDT  ", 0x06040000, ACPI_DSDT, less_than_or_equal, "Multiple problems", 1},

Once you’ve commented out the line that corresponds to your BIOS, recompile your kernel and reboot. The ACPI drivers should now initialize, and the messages about the blacklisted BIOS should go away. You may also have to boot with “acpi=force” on the kernel line of your grub.conf to get this to work (thanks to sleek for clarifying).

10e. I have an Asus laptop

If you have an Asus laptop, you may want to check out the acpi4asus project. This is a driver that provides ACPI support on linux for most Asus laptops, including special keys and LEDs. The driver is being actively developed, so if you have a recent Asus laptop that isn’t yet supported by the driver, support may be coming soon.

10f. It’s still not working!

If, at this point, you are still having errors, there are one or two more things to try. If ACPI refuses to initialize, you can try booting with “acpi=force” in your grub.conf. This is sometimes necessary in order to force the ACPI drivers to initialize with older BIOSes. If you still have ACPI-related errors on boot and have a single-processor machine, then try disabling multiprocessor support, local apic support and IO-apic support in your kernel. You can also try booting with the “pci=noacpi” or “noapic” options. The apic code still seems to be a bit finicky; many people have reported problems with it.

If none of the above recommendations helps, then I would strongly suggest contacting the ACPI developers. You have likely found a bug in the ACPI code. In particular, if you are having suspend/resume problems, you are far from alone. This code is still being worked out. Give the acpi-devel mailing list a shot. You can also, of course, post your errors here, and I’ll try to see what I can do to help, but the acpi gurus are likely to be a better resource.

11. Useful ACPI resources

There are a number of good ACPI resources, in case you get stuck. The ones that I found most helpful were:

bugzilla.kernel.org
acpi.sourceforge.net
acpi-devel and acpi-bugzilla mailing lists
www.acpi.info (the ACPI spec is here, including ASL documentation, which is the language used for the DSDT)
The Intel ACPI downloads page - get the iasl compiler here.
HOWTO fix common DSDT errors
DSDT fixes for the Thinkpad T31
DSDT repository at acpi.sourceforge.net
DSDT submission page at acpi.sourceforge.net.
Documentation for the static DSDT override
Documentation for the initrd DSDT override
ECDT initialization patch
FF button patch
acpi4asus homepage

12. Acknowledgements

I’d like to thank the ACPI developers, especially Luming Yu and Bruno Ducrot. All of them have been very helpful and very responsive. In general, the ACPI mailing lists and bugzilla are wonderful resources for ACPI help.

The IndieWeb has captured my imagination in a way that nothing has since I was introduced to Linux in the early 2000’s. I feel the same sense of exploration and community, but I also sometimes get the same sense of impenetrability that characterized the Linux experience in those days. Most of my early reading on the IndieWeb turned up talk of principles and protocols. I kept running into terms like “ActivityPub” and “Micropub” and “webmention” when what I was looking for was more like a how-to guide. It’s all fascinating reading, but it was daunting as someone who was just trying to figure out how to write something on the IndieWeb.

Fortunately, it turns out that I didn’t have to know any of that to post on the IndieWeb. Most of that information is directed to people who want to build an IndieWeb site. Now that I have my bearings, I thought it would be fun to see if I could get a second account on the IndieWeb in 5 minutes. I got pretty close! It was essentially 3 steps. Here’s the short version:

1. Create a Micro.one account
2. Start a Micro.one subscription ($1/month)
3. (optional) Get a domain name ($16/year)

The best thing about this is that it can all be done from Micro.one without any specialized knowledge.

The rest of this post will cover the steps I took in detail. My hope is that this can act as a quickstart for people like me who are interested in joining the IndieWeb but don’t want to build a website to do it. Even if you’ve never considered running a web server or registering a domain, you should be able to get your own site on the IndieWeb by following this guide. If you’re still having trouble after reading it, then I’ve fallen short of my goal. Please let me know in the comments and I’ll improve the guide. I’ll also help you out as much as I’m able.

Let’s jump in!

The subjects: My cats

The one hitch in my 5-minute IndieWeb plan was that I’d already set up this site, so I didn’t need another one. Fortunately, I have a couple of cats who still haven’t gotten around to setting up their own site. So I thought I’d be a good cat caretaker and get them on the IndieWeb. It’s time the internet met Cooper and Cole.

As you can see, they’re extremely busy.

The Platform: Micro.one

Micro.one is a thoughtfully designed, IndieWeb-friendly blogging service from Manton Reece. It supports short-form and long-form posts, photos, podcasts, and even things like bookshelves to keep track of your reading. It’s a great place to make your first home on the IndieWeb.

It’s a paid service at $1/month. This allows Manton to provide Micro.one without ads.

Create a Micro.one account

Go to the Micro.one homepage and click the “Sign Up” button in the top right.

You’ll be taken to a Registration page that asks for the usual sign up info: name, username, email address. Fill in the information and click “Register.”

You’ll get an email from Micro.blog at the address you used to register. Open the email and click the “Confirm your account” button to complete the registration. When you do, you’ll be taken to the timeline on Micro.one. Congratulations! You’re on the IndieWeb!

Start a Micro.one Subscription

Great! Cooper and Cole are on the IndieWeb. But before they can post on their new Micro.one blog, I need to start a subscription for them (I don’t trust them with their own credit cards yet). If you try to post before setting up a subscription, you’ll see a prompt to upgrade your plan.

Click the “Please upgrade” link and you’ll be taken to the Plans page (you can also get there by clicking “Plans” on the left-hand sidebar). Select the Micro.one plan and click the “Start Subscription.” button.

You’ll be prompted for your credit card information. Once you’ve entered it, your plan will be upgraded and you can post! Go ahead and click the New Post button and give it a try. The cats could hardly wait to get started.

After you click “Publish Post,” you’ll see a message that the post was published to your blog at the top of the screen. In the lower right corner, there will be a message that says “Finished publishing post” with a link to view the post. Click that link, and you’ll be taken to the post on your blog.

Your blog’s address will be your_micro_one_username.micro.blog. In my cats' case, this is cooperandcole.micro.blog. You can stop right here and you’ll have a home on the IndieWeb. Your posts will be published to your blog, and you can share its address with friends and family (or not! It’s up to you).

But in just another couple of minutes, you can make that home your home. Instead of your_micro_one_username.micro.blog, your site can have a unique identity like your_nickname.com or your_full_name.net. There are a lot of reasons why you may want to do this, but one of the main ones is that it’s just fun to have your own address on the internet. It’s also a core principle of the IndieWeb. Let’s set that up now!

Get a domain name

In internet terms, the address of your website is called a domain. You can get a domain name without even leaving Micro.one. Click the “Account” link on the left-hand sidebar. Go down to the “Blogs” section and click the “Get a Domain” button.

You’ll be taken to a screen where you can search for a domain name. Cooper and Cole wanted to make it clear that their site presents a feline perspective, so they settled on cooperandcolethecats.org. Enter the domain name you want into the box and click the “Check Availability” button to see if it’s available for your site.

If the domain is available, you’ll be asked to enter your contact information. This is a standard requirement for registering a domain. It helps to ensure that domains are registered to real people. But don’t worry, your contact information won’t be exposed to the internet. Instead, the domain will show the contact details for name.com (this is who Micro.one uses for domain registration).

The cost for the domain will be charged to the credit card you used to register for Micro.one. The cost will depend on the type of domain you register (.com, .org, .net, …), but you can expect it to be something like $15-$25 a year.

Click the “Register” button at the bottom of the page, and Micro.one will register the domain and configure it to work with your site!

This step takes some time. In my case, it took about two hours for the domain registration to go through. While you’re waiting, it’s a great time to set up your Micro.one profile. You can add a photo, name, and an about statement and they’ll be displayed on your site.

When the registration is complete, you’ll get an email from Name.com with a prompt to confirm your email address. You need to do this in order to complete the domain registration. Click the button in the email, and in a couple minutes your Micro.one site will show up on your new domain! You can see the cats' site at www.cooperandcolethecats.org

Welcome to the IndieWeb!

Congratulations! You now have a home on the IndieWeb. There’s all sorts of things you can do from here: post some thoughts, write an article, share some photos, follow interesting accounts and ideas (Maggie Appleton’s post on digital gardens is a great example of both to get you started).

If you’d like to learn more about the philosophical and technological underpinnings of the IndieWeb, the IndieWebCamp wiki has all kinds of great material. If you want to hang out with other people who are passionate about the IndieWeb, their discord server is supportive and friendly.

Above all, have fun! It’s a vibrant community that fosters creativity and nourishes curiosity. I can’t wait to see what you bring to it!
